Mechanical

Frame

Aluminum Alloy Material, SS8MD New Eel Frame

Wheel Size

650B 36H Front and Rear

Fork

NEX DS 700C Non-Lockout / Teeth Headtube: Ñ„28.6×Ñ„25.4 *183MM / Disc Brake / Travel Distance: 63MM

Handlebar

PROMAX HB-T305 17.5（Inner Size）*25.4*W620*162*9*H60 P48 ENC

Stem

PROMAX MQ-565S

Seatpost

SP-252 28.6*400mm

Seat Clamp

Alloy Quick Release 28.6mm

Saddle

VELO VL-6100 GEL

Shifters

Single Speed Drive Simplicity / 3 or 5 Level PAS

Derailleur

SHIMANO ACERA ARDM360SGSL / Black

Rims

POWER CIRCLE P23DM 36H Double Wall Alloy

Hubs

MODUS JA159F-DSE-QR

Hubs

MODUS JA259R-DSS 3/8*13*36*135*190

Spokes

13g 2.2mm F / 12g 2.6mm R Stainless Steel 265mm/267mm

Tyres

Schwalbe Super Moto-X 27.5in x 2.4in Tyres

Cranks

PROMAX E44PP/32 170MM 44T

Pedals

YONGHUA 8X

Chain

KMC Z51/RB/140L

Brakes Front

Tektro Hydraulic Disc Brakes

Brakes Rear

Tektro Hydraulic Disc Brakes

Brake Levers

Tektro Hydraulic Brakes Levers

Mudguards

Black Plastic 650B x 65mm

Stand

Chain Stay Side Mount Adjustable Alloy

Rear Rack

Alloy 650B / 700C Pannier Compatible

Electrical

Motor

250W Mivice Rear Hub Motor – Dayco Belt Drive

Efficiency

Greater than 80%

Torque

95Nm – Integrated Torque Sensor

Controller

Mivice – 15Amp Digital Internal Integration

Battery

36V 475mWh (13.2Ah) Samsung Lithium Battery

Battery Life

Up to 800 recharges from flat

Battery Weight

2.4kg

Display Panel

Full Colour KD86 With USB Port

Operation Controls

Left Handlebar Mivice Compatible

Pedal Activation

Mivice Motor Integration

Light Front

BUCHEL LED 51252712 Static Illumination

Light Rear

BUCHEL LED 51254523 Static Illumination

Charger

Sans 36V 2Amp Lithium AU Compliant

Main Cable

JULET 1T5 Waterproof Quick Release

Audible Warning

HONKA HOOTA Black

Max Speed

25kmh

Max Range

80km 1:1 Pedal Assist

Bicycle Weight

24kg incl battery

Sizing

Seat Tube

450mm

Step Over

450mm

Max Seat Height

1080mm

Min Seat Height

850mm

Length

1820mm

Width

670mm
