Mechanical

Frame

Hydroformed Alloy, 27.5 Step Through frame, internal cable routing head tube ported, removable down tube battery with security lock, accessory ready rear cargo rack

Frame Colour

Burgundy

Fork

RST BLAZE-27.5TNL-15, 80mm travel, lockout, Thru Axle

Shifters

SHIMANO ALIVIO 9-speed Rapidfire Plus

Chainrings

42T with Narrow Wide teeth

Chain

KMC E9-S

Rear Derailleur

SHIMANO ALIVIO 9-speed

Cassette

SHIMANO ALIVIO 9-speed 11-34T

Handlebar

640mm, 45mm rise, 31.8mm dia.

Grips

VELO, Ergonomic, 135mm

Stem

80mm with 7 degree rise

Seatpost

31.6mm (350mm)

Saddle

SELLE ROYAL Rio

Brake Levers

TEKTRO HDE350 with power cut off switch

Brake Calipers

TEKTRO HDE350 Hydraulic Disc

Rotors

180mm

Tyres

WTB GROOV-E 27.5”x2.4”, 60tpi

Rims

27.5”, Dual Wall Alloy, black

Electrical

Bluetooth

NEW iGO Mobile App (Android and iOS). Customizable profile and performance settings with full diagnostic monitoring and alerts.

Display Unit

2” HD High Brightness IPS Color LCD Display, Ergonomically Designed Buttons, IP65 Waterproof, Password Protected Power On Option, USB Charging Port, Light Auto On/Off Option (Ambient Light Detector), Interface Color Coded Display Reference (for Quick Glance Safety), Main Power/PAS Control/Ride, Stats and Settings Toggle, PAS Level/Battery/Power/Clock, Speedometer/Max Speed/Avg Speed, Trip Distance, Battery Voltage/Capacity Percentage/Range/Accumulated Charging Cycles, Motor Power Output Average/Maximum, Ride Analysis Statistics, Diagnostic and Warning Information, Walk Assist

Motor

iGO DRIVE LS 350W mid motor, 48V

Torque

up to 100Nm

Battery

5000mAh SAMSUNG cell, removable with security lock (48V | 15Ah | 720Wh)

Range

110km

Pedal Assist System

Eco/Tour/Sport/Turbo/Boost color coded per PAS level

Sensor

Internal Torque, Cadence, Speed

Other

Accessories (included)

Front LED light XC-259A (powered by main battery), Rear LED SPANNINGA LED Commuter Glow XE with brake light Integrated into rear rack (powered by main battery), Front & Rear  Fenders, Rear Cargo Rack Accessory ready, Integrated Chainring Guard, Water Bottle Bosses on Seat Tube, Kickstand, Wellgo Pedals, Bell, Tool Kit, Battery Charger

Bike Weight (w/o battery)

25.3kg

Weight Capacity

125kg

Battery Weight

3.5kg
