NO SHIPPING ON BIKES
Key Performance Factors
Modern MTB Design
Tapered fork steerer tubes*, quality components like a 1x drivetrain* with a clutch-equipped rear derailleur, thru-axle hubs*, internal cable routing (including dropper post compatibility), and integrated chainstay protection provide everything you need to build confidence and skills on the trails. (*select models)
Off-Road Control
The new geometry is optimised for confident trail riding, with two wheel size options (27.5 or 29-inch) based on frame size. It’s also designed to match front suspension travel with either an 80mm or 100mm fork. All models have clearance for high-volume tyres (up to 2.4 inches) for traction and grip on technical terrain.
Light and Durable
The all-new ALUXX aluminium frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.

• Frame
ALUXX-grade aluminium, disc
• Fork
SR Suntour XCE 28, coil spring, 100mm, QR, steel steerer
• Shock
N/A
• Handlebar
Giant Connect Trail, 31.8mm
• Grips
Giant Sole-O
• Stem
Giant Sport, 7-degree S: 40mm M: 50mm
• Seatpost
Giant Sport, 30.9mm
• Saddle
Liv ErgoContact Trail
• Pedals
MTB caged
• Shifters
microSHIFT Acolyte, 1x8
• Front Derailleur
N/A
• Rear Derailleur
microSHIFT Acolyte, M5185M w/clutch
• Brakes
TKB-172, mechanical [F]160mm, [R]160mm rotors
• Brake Levers
Alloy
• Cassette
microSHIFT H083, 12x46
• Chain
KMC 8.3
• Crankset
Prowheel Forged, 32t S: 170mm M: 170mm
• Bottom Bracket
Cartridge
• Rims
Giant GX03V 29 alloy, double wall
• Hubs
Alloy, sealed
• Spokes
Stainless, 14g
• Tires
Maxxis Ikon 29x2.2", wire bead
• Extras
2.4" max tyre size, 32t max chainring size
