Key Performance Factors

Modern MTB Design

Tapered fork steerer tubes*, quality components like a 1x drivetrain* with a clutch-equipped rear derailleur, thru-axle hubs*, internal cable routing (including dropper post compatibility), and integrated chainstay protection provide everything you need to build confidence and skills on the trails. (*select models)

Off-Road Control

The new geometry is optimised for confident trail riding, with two wheel size options (27.5 or 29-inch) based on frame size. It’s also designed to match front suspension travel with either an 80mm or 100mm fork. All models have clearance for high-volume tyres (up to 2.4 inches) for traction and grip on technical terrain.

Light and Durable

The all-new ALUXX aluminium frame features updated tube shaping and a lighter overall weight for improved performance on off-road terrain.

•Â Â Frame

ALUXX-grade aluminium, disc

•Â Â Fork

SXC32-3 RL, coil spring, Boost 15x110 XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (29)

•Â Â Shock

N/A

•Â Â Handlebar

Giant Connect Trail, 31.8mm

•Â Â Grips

Giant Sole-O

•Â Â Stem

Giant Sport, 7-degree XS: 40mm (27.5) S: 40mm (27.5) / 40mm (29) M: 50mm (29)

•Â Â Seatpost

Giant Sport, 30.9mm

•Â Â Saddle

Liv ErgoContact Trail

•Â Â Pedals

MTB caged

•Â Â Shifters

MicroShift Advent, 1x9

•Â Â Front Derailleur

N/A

•Â Â Rear Derailleur

microSHIFT Advent, M6195M w/clutch

•Â Â Brakes

Tektro TKD149, hydraulic, Tektro rotors [F]180mm, [R]160mm

•Â Â Brake Levers

Tektro TKD143

•Â Â Cassette

microSHIFT H093, 11x46

•Â Â Chain

KMC X9

•Â Â Crankset

ProWheel Charm, 32t (27.5) or 30t (29) XS: 165mm (27.5) S: 165mm (27.5) / 170mm (29) M: 170mm (29)

•Â Â Bottom Bracket

Cartridge

•Â Â Rims

Giant GX03V 29 or 27.5, alloy, double wall

•Â Â Hubs

Alloy, sealed

•Â Â Spokes

Stainless, 14g

•Â Â Tires

Maxxis Rekon 27.5x2.4" or Maxxis Rekon Race 29x2.4", wire bead

•Â Â Extras

2.4" max tyre size, 32t max chainring size
