Key Performance Factors

Modern MTB Design

Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control

New geometry is optimised for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size and model. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size and model. All models have clearance for high-volume tyres (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable

All-new ALUXX aluminium frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

• Frame

ALUXX-grade aluminium, disc

• Fork

SR Suntour XCE 28, coil spring, QR, steel steerer XS: 80mm travel (27.5) S: 80mm travel (27.5) / 100mm travel (29) M: 100mm travel (29), L: 100mm travel (29) XL: 100mm travel (29)

• Shock

N/A

• Handlebar

Giant Connect Trail, 31.8mm

• Grips

Giant Sole-O

• Stem

Giant Sport, 7-degree XS: 40mm (27.5) S: 50mm (27.5) / 50mm (29) M: 60mm (29) L: 70mm (29) XL: 80mm (29)

• Seatpost

Giant Sport, 30.9mm

• Saddle

Giant ErgoContact Trail

• Pedals

MTB caged

• Shifters

Shimano Altus, 2x8

• Front Derailleur

Shimano Altus

• Rear Derailleur

Shimano Acera

• Brakes

Tektro TKD143, hydraulic, Tektro rotors [F]180mm, [R]160mm

• Brake Levers

Tektro TKD143

• Cassette

Shimano HG31, 11x34

• Chain

KMC 8.3

• Crankset

Shimano FC-M315, 22/36 XS: 170mm (27.5) S: 170mm (27.5) / 170mm (29) M: 170mm (29) L: 170mm (29) XL: 175mm (29)

• Bottom Bracket

Cartridge

• Rims

Giant GX03V 29 or 27.5, alloy, double wall

• Hubs

Alloy, sealed

• Spokes

Stainless, 14g

• Tires

Maxxis Ikon 27.5" or 29x2.2", wire bead

• Extras

2.4" max tyre size, 32t max chainring size
