Key Performance Factors

Modern MTB Design

Tapered fork steerer tubes*, quality components including a 1x drivetrain* with clutch-equipped rear derailleurs, thru-axle hubs*, internal cable routing (including dropper seatpost) and an integrated chainstay protector give aspiring trail riders room to grow. *on select models

Off-Road Control

New geometry is optimised for confident trail riding and two different wheel sizes (27.5 or 29-inch) depending on frame size and model. The geometry is also designed for front suspension with either an 80mm or 100mm fork depending on frame size and model. All models have clearance for high-volume tyres (up to 2.4-inch) for traction and grip on technical terrain.

Light and Durable

All-new ALUXX aluminium frame features updated shaping and a lighter overall weight for improved performance on off-road terrain.

•Â Â Frame

ALUXX-grade aluminium, disc

•Â Â Fork

SXC32-3 RL, coil spring, 100mm, Boost 15x110

•Â Â Shock

N/A

•Â Â Handlebar

Giant Connect Trail, 31.8mm

•Â Â Grips

Giant Sole-O

•Â Â Stem

Giant Sport, 7-degree S: 50mm M: 60mm L: 70mm XL: 80mm

•Â Â Seatpost

Giant Contact Switch Core dropper, remote S: 100mm travel / 30.9 x 350mm M: 120mm travel / 30.9 x 400mm L: 120mm travel / 30.9 x 400mm XL: 120mm travel / 30.9 x 400mm

•Â Â Saddle

Giant ErgoContact Trail

•Â Â Pedals

MTB caged

•Â Â Shifters

Shimano CUES SL-6000, 1x10

•Â Â Front Derailleur

N/A

•Â Â Rear Derailleur

Shimano CUES, U6000, Shadow+

•Â Â Brakes

Tektro TKD143, hydraulic, Tektro rotors [F]180mm, [R]160mm

•Â Â Brake Levers

Tektro TKD143

•Â Â Cassette

Shimano CUES, CS-LG300, 11x48

•Â Â Chain

KMC X-11

•Â Â Crankset

ProWheel Charm, 30t S: 170mm M: 170mm L: 170mm XL: 175mm

•Â Â Bottom Bracket

Cartridge

•Â Â Rims

Giant GX03V 29 alloy, double wall

•Â Â Hubs

Alloy, sealed bearing, [F] 15x110 thru axle, [R] 12x142 thru-axle

•Â Â Spokes

Stainless, 14g

•Â Â Tires

Maxxis Rekon Race 29x2.4", wire bead

•Â Â Extras

2.4" max tyre size, 32t max chainring size
